    Stone Photo Co2 Laser Engraving Machine 1200*900mm

    Ask Lasest Price
    Brand Name : UPGOAL
    Model Number : UG-1290L
    Certification : CE/FDA
    Price : USD 2010-USD 2250 FOB QINGDAO
    Payment Terms : T/T, L/C, Western Union, MoneyGram, D/A, D/P
    Supply Ability : 200 sets/month
    Delivery Time : Within 7 working days
    • Product Details
    • Company Profile

    Stone Photo Co2 Laser Engraving Machine 1200*900mm

    Stone Photo Co2 Laser Engraving Machine 1200*900mm


    Application


    Application industry: Marble engraving, Advertisment, Gift Package, Model.


    Application Materils:Acrylic,crystal, marble, wood, paper, cloth, leather, rubber, glass, ceramic tile.


    Features


    Separated Structure


    Upper and lower separation design. The Upper parts can be taken down and set up onto the stone as solution for heavy stones while materials loading difficulties and platform load bearing is limited.


    Manual Lifting Handle


    Distance between the two parts can be adjusted which is Much more convenient for thicker materials

    processing


    Laser Head


    Newly desgin, More in according with mechanical engineering. Safe and Durable. Simple Operation with high engraving/cutting speed and high laser power convert ratio.


    Laser Tube


    Adopted famous Reci S2 Co2 laser tube, rated power: 90W, peak power: 100W, long time time and stable


    Working Table


    Honey Comb Table: applicable to variosu soft materials with Good adsorption effect and low reflection ratio.


    Up-Down Table:Maxmum Loading 50kgs with 300mm up-down distance.


    Beam Path System:


    Adopting imported focus lens with high luminousness and mirro with high reflectivity ensure stable power transference.


    Motion System


    Imported High precison,low friction force and stand wear and tear linear square guide rails and blocks with 3M beltensured stable transimission, lower noise


    Operation System


    Advanced USB port Leetro DSP control system with large inner memory device and Fast curvilinear cutting and Optimized shortest path function, Greatly improved the working efficency .


    With full-process automatic laser power attenuation compensation , ensuring the performance consistency of engraving/cutting. The High speed motion control programm with pre-buffering function enhances productivity more.


    Completely compatible with various CAD&CAM softwares such as AuotCAD, CorelDAW, supporting the desgins directly exporting. With advanced Color management and defining the working turns with different colors , All or a part work can done in one time.


    Rationalized placement of the electronic parts. Optimized heat dissipation effect.


    Cooling System


    Industrial chiller CW-5000, ensuring the laser tube long time continus working


    Technical parameters

    Effective working area1200*900mm
    Laser TypeCo2 sealed-off laser tube
    Laser tube power

    S2 series, Reci, Beijing

    (Rated power: 90W, max. Power: 100W)

    Working tableHoney comb
    Driver mode3 phases stepper motor and Driver, Yako brand
    Guide railLinear square guide rail ( Hiwin,Taiwan)
    TransmissionBelt transmission
    Control panelEnglish
    Laser output control1-100% software setting
    Engraving speed0-60000mm/min
    Cutting speed0-10000mm/min
    Control systemLeetro MPC6585
    Control softwareLaserCut 6.1
    Design software when deliveryCorelDraw
    Control panelDSP offline
    Resolution accuracy< 0.01mm
    Location precision< 0.01mm
    Highest scanning accuracy2500DPI
    Type of coolingIndustrial chiller, CW-5000 cooling
    Water protection systemYes
    Blow-off system

    Air pump for the laser head

    Air blower for the machine

    Biggest scanning accuracy2500DPI
    Working temperature0-45 °C
    Operating humidity5-95% (without condensed water)
    Supporting picture formatPLT,DST,DXF,BMP, DWG,AI,LAS,etc
    VoltageAC 220V+10% 50/60Hz, single phase
    CertificateCE/FDA

    Reference Parts Photos


    Honey comb working table with less knife strip supporting


    Laser head


    Manual lifting handwheel


    Auto lifting table


    Reference Sample Photos


    Reference Working Videos


    https://www.youtube.com/watch?v=kdVv4MKhh_s&index=10&list=PLZ2SG5kTfvfOCXsQbxHpyInEaDg01cVvL


    For more information, just feel free to contact us!

    Jinan Upgoal Mechanical Equipment Co.,Ltd

    Supplying & Servicing for CNC Router/Laser Engraving Cutting Machine/Plasma Cutting Machine/Marking Machine/CNC Wood Lathe
